Eaton BJ2100 – 100 Amp, 2-Pole Circuit Breaker

Overview

The Eaton BJ2100 is a 100 Amp, 2-pole circuit breaker from Eaton's BJ Series, designed for use in residential and light commercial applications. This plug-on breaker offers reliable protection against overloads and short circuits, ensuring the safety and integrity of electrical systems.

Key Features

• Amperage Rating: 100 Amps

• Voltage Rating: 120/240 VAC

• Poles: 2 (double-pole configuration)

• Interrupting Rating: 10,000 AIC (Ampere Interrupting Capacity) at 240V

• Connection Type: Plug-on design for easy installation

• Trip Type: Common thermal magnetic protection

• Wire Size Compatibility: Accepts #2 AWG to 300 kcmil copper or aluminum conductors at 60–75°C

• Certifications: UL 489 Listed, Federal Specification W-C-375

• Dimensions: Approximately 6.5 inches (L) x 3.5 inches (W) x 2.5 inches (H)

• Weight: 1.8 lbs

Benefits

• Reliable Protection: Provides dependable overload and short-circuit protection to safeguard electrical circuits.

• Easy Installation: Plug-on design simplifies installation and replacement in compatible load centers.

• Durable Construction: Built to meet stringent UL and federal specifications for safety and reliability.

• Versatile Compatibility: Suitable for various residential and light commercial applications requiring 240V circuits.

Applications

• Main circuit protection in residential load centers

• Sub-feed applications in multi-metering systems

• Replacement breaker for Eaton Type BR load centers

• Protection for 240V appliances such as water heaters, HVAC systems, and electric dryers
