The Murray MP2100KH is a 100 Amp, 2-pole circuit breaker designed for use in Murray Type MP load centers. This plug-in breaker offers reliable protection against overloads and short circuits, ensuring the safety and integrity of electrical systems.
Key Features
Amperage Rating: 100 Amps
Voltage Rating: 120/240 VAC
Poles: 2 (double-pole configuration)
Interrupting Rating: 10,000 AIC (Ampere Interrupting Capacity) at 240V
Connection Type: Plug-on design for easy installation
Trip Type: Thermal magnetic protection
Wire Size Compatibility: Accepts 8–2/0 AWG copper or aluminum conductors at 60–75°C
Certifications: UL 489 Listed, CSA Certified, NEMA AB1
Dimensions: Approximately 3" (W) × 3" (D) × 3-1/8" (H)
Weight: 0.45 lbs
Benefits
Reliable Protection: Provides dependable overload and short-circuit protection to safeguard electrical circuits.
Easy Installation: Plug-on design simplifies installation and replacement in compatible load centers.
Durable Construction: Built to meet stringent UL and CSA specifications for safety and reliability.
Versatile Compatibility: Suitable for various residential and light commercial applications requiring 240V circuits.
Applications
Main circuit protection in residential load centers
Sub-feed applications in multi-metering systems
Replacement breaker for Murray Type MP load centers
Protection for 240V appliances such as water heaters, HVAC systems, and electric dryers
