Overview:
The Murray MPD2150 is a 150-amp, 2-pole thermal-magnetic circuit breaker designed for use in residential and light commercial electrical systems. Engineered for plug-on mounting, it offers reliable overcurrent protection and is compatible with Murray load centers.
Key Specifications:
Model Number: MPD2150
Amperage Rating: 150 amps
Voltage Rating: 120/240 VAC, single-phase
Interrupting Capacity: 10,000 AIC (Amps Interrupting Capacity) at 240 volts
Poles: 2
Mounting Style: Plug-on installation
Trip Type: Thermal-magnetic (LI type — long-time and instantaneous)
Conductor Size: Suitable for 4 AWG to 300 kcmil copper or aluminum conductors
Frame Type: MD-T
Enclosure Type: NEMA 3R
Dimensions: Approximately 9 inches (L) x 6 inches (W) x 3 inches (H)
Certifications: UL Listed, NEMA AB-1 compliant
Application: Main and branch circuit protection in load centers and meter modules
