SIEMENS
Siemens BE230 30-Amp Double Pole 120/240-Volt Circuit Breaker
Siemens BE230 30-Amp Double Pole 120/240-Volt Circuit Breaker
Couldn't load pickup availability
Overview
The Siemens BE230 is a 30-amp, 2-pole, 120/240-volt thermal-magnetic circuit breaker designed for residential and light commercial applications. It provides reliable overcurrent protection and is suitable for use in Siemens load centers.
Key Features & Specifications
| Feature | Specification |
|---|---|
| Amperage Rating | 30 A |
| Voltage Rating | 120/240 VAC |
| Number of Poles | 2 |
| Phase | Single-phase |
| Interrupting Capacity | 10 kA at 240 VAC |
| Trip Type | Thermal/Magnetic |
| Mounting Type | Bolt-on |
| Frame Size | 60A/BLE |
| Wire Size Compatibility | 14–8 AWG copper or 12–10 AWG aluminum |
| Temperature Rating | 40°C (104°F) |
| Dimensions (L x W x H) | 6.2" x 3.6" x 2.5" |
| Certifications | UL Listed, CSA Certified, HACR Rated |
Benefits
-
Reliable Protection: Offers dependable overcurrent protection for circuits, safeguarding wiring and connected devices.
-
Compact Design: The 2-pole configuration allows for efficient use of panel space.
-
Durable Construction: Designed to withstand demanding environments, ensuring long-term reliability.
-
Easy Installation: Bolt-on mounting simplifies the installation process in compatible Siemens load centers.
Typical Applications
-
Residential: Ideal for protecting circuits supplying 240V appliances such as dryers, ranges, and HVAC systems.
-
Light Commercial: Suitable for small businesses requiring reliable circuit protection.
-
Load Centers: Specifically designed for use in Siemens load centers, ensuring compatibility and optimal performance.
