Square D Homeline HOMT1520CP 1‑Space Tandem Circuit Breaker (15 A + 20 A, 120/240 VAC)

Overview

The Square D HOMT1520CP is a tandem single-pole circuit breaker designed to deliver compact, efficient protection in residential load centers. It features two independent breakers—one rated at 15 amps and the other at 20 amps—within a single breaker space, making it ideal for expanding circuits when panel space is limited.

Key Specifications

• Type: Tandem (Single-Pole) Circuit Breaker

• Amperage Ratings: 15 A and 20 A

• Voltage: 120/240 VAC

• Interrupting Capacity: 10,000 AIC (10kA)

• Poles: 1 pole per circuit (2 total circuits)

• Mounting Style: Plug-On

• Compatibility: Designed for use with Square D Homeline load centers and combination service entrance devices (CSEDs)

• Wire Range: #14 to #8 AWG copper or aluminum

• Trip Type: Thermal-magnetic

• Dimensions (H × W × D): Approx. 3.13" × 1.00" × 2.98"

• Certifications: UL Listed, HACR type

• Warranty: Limited Lifetime (when used in Homeline panels)

Features & Benefits

• Space Saving: Allows for two circuits in a single panel slot, helping conserve space in a full load center.

• Reliable Protection: Provides thermal-magnetic circuit protection against overloads and short circuits.

• Fast Installation: Plug-on design offers quick and secure mounting into compatible Homeline panels.

• Versatile Use: Suitable for lighting, outlets, and small appliance circuits in residential settings.

• Code Compliant: UL listed and HACR rated for broader electrical code compatibility.

Common Applications

• Expanding existing residential panels without adding new spaces

• Split circuit installations for lighting and receptacles

• HVAC, refrigeration, or other branch circuit applications

• Renovation and retrofit projects where breaker space is limited
